The material roll is uncoiled and levelled by the uncoiler and leveller 2 in 1, and then feed to mould by the zigzag feeder. The middle conveyor receives the material from the 1st punch and transfers it to the next punch by 3D transfer manipulator. Manipulator works with the punch to complete the product by 12 steps process, such as blanking, drawing, and finally the product is sent out by the con

It is the first automatic production line which can straighten thickness up to 20mm in China. The final product is anchor disk（plate anchor) for mining industry. Except uncoiling, leveling and auto feeding function, it also equipped with hydraulic cutting machine and automatic welding machine. Raw material: Q355 high tensile steelThickness: 4-20mmCoil width:100-400mmFeeding speed: 16m/min， 32-35 s

Project worked together with YANDON for CNI Thailand. Line configuration: 1,Decoiler, straightener and feeder 3 in 12,Trolley car

High strength steel stamping line worked together with YANDON for Jennmar USA. As for the excellent performance , when Jennmar new plant was established in Tianjin China 2022, we are proud to be their tier 1 supplier and designed /manufactured another 2 sets high strength decoiler, straightener and feeder with automatic welding function. Line configuration: 1,Decoiler, straightener and feeder 3 in

Automatic loading, feeding, stamping and unloading line for R.bourgeois France. Line configuration: 1,Decoiler, straightener and feeder 3 in 12,Trolley car
